Airbus and the University of Surrey, England, have developed a robust multilayer nano-barrier for ultra-lightweight and stable carbon fibre reinforced polymers. It could be used to build instruments for future space missions.


Airbus has been using Carbon fibre reinforced polymers (CFRPs) on its spacecraft and instrument structures for many years. Good examples are the two GRACE FO satellites that are tracking movement of liquid water, ice and land masses due to climate change, and BepiColombo which will explore Mercury. On those type of missions CFRPs offer many advantages; in particular a high strength to weight ratio.

But applications are limited because the material absorbs moisture, often released as gas during a mission. This affects the dimensional stability and alignment of optical payload structures. Engineers can try to minimise this problem by performing long, expensive procedures such as drying, recalibrations and bake-out – all of which may not completely resolve the issue.

From left: Prof. Ravi Silva, Director of the Advanced Technology Institute at University of Surrey; Michal Delkowski, Development Engineer and Project Technical Lead at Airbus Friedrichshafen; and Dr. Jose Anguita, Dr. Christopher Smith and James Hodges from the University of Surrey)

Now, Scientists and engineers from Airbus and the University of Surrey have found a solution: a multi-layered nano-barrier that bonds with the CFRP and eliminates the need for multiple bake-out stages and the controlled storage required in its unprotected state.

Professor Ravi Silva, Director of the Advanced Technology Institute at the University of Surrey, is confident that the newly developed reinforced composite is a "significant improvement over similar methods and materials already on the market."

In a paper published by scientific journal Nature Materials, the engineers showed that their thin barrier – measuring only sub-micrometres in thickness, compared to the tens of micrometres of current space mission coatings – is less susceptible to stress and contamination at the surface, keeping its integrity even after multiple thermal cycles.

"These encouraging results suggest that our barrier could eliminate the considerable costs and problems associated with using CFRPs in space missions,"

Professor Ravi Silva, Director of the Advanced Technology Institute at the University of Surrey

Christian Wilhelmi, Head of Mechanical Subsystems and Research and Technology at Airbus in Friedrichshafen, is equally positive: "The new nano-barrier, together with our ultra-high-modulus CFRP manufacturing capability, will enable us to create the next generation of non-outgassing CFRP materials, with much more dimensional stability. Reaching this milestone gives us the confidence to look at instrument-scale manufacturing to fully prove the technology."

In future, the coating could offer significant benefits in other areas of Airbus' business too. For example, increase of wear resistance, barrier properties for many kinds of substances, protection from atomic oxygen erosion in Low Earth Orbit, adjustments of thermo-optical properties and more.

Airbus Coating Facility Installed At UoS

"Years of cooperation with the University of Surrey, painstaking work and collaboration with customers like ESA and DLR have rewarded us with a leading edge technology, with at least one order of magnitude better performance than any other existing solution," says Paolo Bianco, R&T Cooperation Manager. "I'm delighted to see yet another R&T cooperation resulting in recognised, concrete technology that will soon fly."

The new nano barrier could be used for upcoming Earth, Navigation and Science programmes such as Copernicus Extension, Earth Explorer and Science Cosmic Vision.
