An innovative process for composite repairs on jetliners such as Airbus’ A350 XWB has been developed by an Airbus working group from company locations in Spain, Germany, the UK and France – with the procedure validated on an A350-900 flight test aircraft.
“Most composite parts used to be removable so they could be repaired in a standard shop,” explained Guillaume Ferrer, embodiment engineering manager, composite repair process development. “This is impossible for the wings and fuselage so new repair techniques were required.”
An R&T working group was formed to explore new repair ideas. The standard process uses an autoclave. “We kept 90% of the process except for the autoclave, which is why these are called out-of-autoclave repairs,” said Ferrer.
While the repair process’ bonded technique is not new, the tools and level of automation are.
The working group developed a portable robotic repair jet that uses water mixed with an abrasive to remove up to 500 sq. cm. of damaged material for replacement with new carbon fibre. The replacement composite material is cured on site – at an airport or maintenance centre, for example – eliminating the need for the large autoclave traditionally employed in the manufacture of composites.
“The repair jet is a new, Airbus-qualified tool,” explained Sebastien Hanser, the major repairs technical project manager. “The machine’s advantages include its ability to repeat tasks and contain carbon dust. It is suited to difficult locations on the aircraft, such as where an operator would be working upside down, and it has a development potential.”
Also new is an inflatable clean room, which brings the environmental specifications used in manufacturing plants close to the aircraft. “Temperature, dust levels and humidity can be managed, allowing us to perform the work that requires clean and dry conditions,” Sebastien added.
During the A350 XWB’s certification, the team used the full-scale test specimen and fatigue tests to qualify their processes and reach Technology Readiness Level 6 (TRL 6). At the end of last year, the team performed a repair on MSN003 in Toulouse to test out the techniques in real conditions.

The innovative Airbus process for out-of-autoclave composite repairs on jetliners was validated in real conditions with one of the flight test A350 XWBs
