H175 technical information
Introduction
The Airbus H175 belongs to the super medium class of helicopters. It offers the best performance in its category, as well as the highest levels of efficiency in all flight modes.
Technical description (all values are at MTOW)
Performance
- Cruise speed
- 267 km/h
- 144 kts
- Max range
- 1,160 km
- 626 NM
- Max endurance
- 6 hr, 9 min
- 6 hr, 9 min
Engine
- Engine type
- 2 x Pratt & Whitney PT6C-67E
- 2 x Pratt & Whitney PT6C-67E
- Takeoff power
- 1,324 kW / 1,776 shp
- 1,324 kW / 1,776 shp
Characteristics
- MTOW
- 7,800 kg
- 17,196 Ib
- External cargo
- 2,700 kg
- 5,952 lb
- Standard fuel tank
- 2,067 kg
- 4,555 Ib
- Passengers
- up to 18
- up to 18
- Pilots
- 1 or 2 VFR/IFR
- 1 or 2 VFR/IFR
Cabin layout
16 seats
Offshore transport
18 seats
Public services
5 crew members, 2 stretchers & 1 medical wall
Search and rescue (SAR)
Configuration VIP
8 seats
ACH Exclusive
10 seats
ACH Exclusive
