H145 technical information
As the quietest helicopter in its class, the twin-engine H145 offers exceptional performance along with upgraded main and tail rotor systems. This guarantees an unprecedented level of performance in both hover and one-engine inoperative conditions.
Technical Description
Performance
| Hover ceiling OGE | 2,729 m |
| Hover ceiling IGE | 3,807 m |
| Recommended cruise speed | 241 km/h |
| Max* range with standard fuel tanks at SL | 650 km |
| Max* endurance with standard fuel tanks SL | 3 h 35 min |
| Flight envelope (temperature | -45°C +50°C |
| Max altitude for TO and landing | 6,096 m |
| Sound level during level flight | 85.7 dB (preliminary data - confidence interval of +/- 0.5 dB) |
Dimensions
| D-value | 13.54 m |
| Rotor diameter | 10.8 m |
| Internal volume (cabin and cargo compartment) | 6.03 m3 |
Characteristics
| Crew + passengers | 1 or 2 pilots and up to 10 passengers |
| Max takeoff weight (MTOW) | 3,800 kg |
| Max takeoff weight with external load | 3,800 kg |
| Useful load | 1,905 kg |
| Engine | 2 x Safran Helicopter Engines Arriel 2E |
| Standard fuel tank capacity | 723 kg |
| Takeoff power | 667 kW / 894 shp |
| Empty weight, Baseline Aircraft Definitions | 1,895 kg |
| Maximum dual cargo hook load (single hook operation) | 1,600 |
| Maximum dual cargo hook load (HEC class D operation) | 800 |
Performance
| Hover ceiling OGE | 8,955 ft |
| Hover ceiling IGE | 12,490 ft |
| Recommended cruise speed | 130 kts |
| Max* range with standard fuel tanks at SL | 351 nm |
| Max* endurance with standard fuel tanks SL | 3 h 35 min |
| Flight envelope (temperature) | -40°C +50°C |
| Max altitude for TO and landing | 20,000 ft |
| Sound level during level flight | 85.7 dB |
Dimensions
| D-value | 44.42 ft |
| Rotor diameter | 35.43 ft |
| Internal volume (cabin and cargo compartment) | 213.16 cu. ft |
Characteristics
| Crew + passengers | 1 or 2 pilot and up to 10 passengers |
| Max takeoff weight (MTOW) | 8,378 lb |
| Max takeoff weight with external load | 8,378 lb |
| Useful load | 4,200 lb |
| Engine | 2 x Safran Helicopter Engines Arriel 2E |
| Standard fuel tank capacity | 1,593.9 lb |
| Takeoff power | 667 kW / 894 shp |
| Empty weight, Baseline Aircraft Definitions | 4,178 lb |
| Maximum dual cargo hook load (single hook operation) | 3,527 |
| Maximum dual cargo hook load (HEC class D operation) | 1,764 |
Configurations
Eight seats for passenger transport
10 passengers
Law enforcement
Emergency medical services
Documents
Civil Range Brochure
Pdf5.45 MB
Civil Range Brochure
Brochure H145
Pdf8.48 MB
Brochure H145
Brochure LAW ENFORCEMENT
Pdf8.39 MB
Brochure LAW ENFORCEMENT
Mission-Powerline Brochure
Pdf8.35 MB
Brochure Mission Powerline
Mission-HEMS Brochure
Pdf8.34 MB
LIFE SAVING
Mission Firefighting Brochure
Pdf8.47 MB
Firefighting
Mission Search and Rescue Brochure
Pdf11.15 MB
Brochure Mission Search and Rescue
Offshore Wind Industry
Pdf5.31 MB
Infographics
H145 infographic
Jpg 557.16 KB
Did you know?
| Total H145 family helicopters delivered (all versions including BK117) | Over 1,865 |
| Total in service helicopters | 1,617 |
| Total accumulated flight hours (all versions including BK117) | Over 7.5 million |
| Customers (all versions including BK117) | Some 330 customers in 70 countries |
