H125 technical information
Airbus’ H125 continues to lead the single-engine helicopter market in all mission segments, benefitting from its high performance and multi-role capacity.
Technical description
Performance
| Hover ceiling OGE @ MTOW, ISA | 3,871 m (EASA certification Q1 2021) |
| Hover ceiling IGE @ MTOW, ISA | 4,420 m |
| Fast cruise speed @ MTOW | 252 km/h |
| Max range @ fast cruise speed | 630 km |
| Max endurance @ fast cruise speed | 4 hr, 27 min |
| Flight envelope (temperature) | -40°C to ISA +35°C limited to 50°C |
| Max altitude flight | 7,010 m |
Dimensions
| D-value | 12.94 m |
| Rotor diameter | 10.69 m |
| Cabin internal volume (excluding pilot's area) | 3.00 m³ |
Characteristics
| Crew + passengers | 1 pilot + up to 6 passengers or 2 pilots + up to 4 passengers |
| Max takeoff weight (MTOW) | 2,250 kg / 2,370 kg (with dual hydraulics) |
| Max takeoff weight with external load | 2,800 kg |
| Useful load | 973 kg / 1,082 kg (with dual hydraulics) |
| Standard fuel tank capacity | 425 kg |
| Engine type | Safran Helicopter Engines Arriel 2D |
| Takeoff power | 710 kW / 952 shp |
Performance
| Hover ceiling OGE @ MTOW, ISA | 12,700 ft (EASA certification Q1 2021) |
| Hover ceiling IGE @ MTOW, ISA | 14,500 ft |
| Fast cruise speed @ MTOW | 136 kts |
| Max range @ fast cruise speed | 340 NM |
| Max endurance @ fast cruise speed | 4 hr, 27 min |
| Flight envelope (temperature) | -40°C to ISA +35°C limited to 50°C |
| Max altitude flight | 23,000 ft |
Dimensions
| D-value | 42.45 ft |
| Rotor diameter | 35.07 ft |
| Cabin internal volume (excluding pilot's area | 105.94 cu ft |
Characteristics
| Crew + passengers | 1 or 2 pilots + up to 6 passengers |
| Max takeoff weight (MTOW) | 4,960 lb / 5,225 lb (with dual hydraulic) |
| Max takeoff weight with external load | 6,173 lb |
| Useful load | 2,146 lb / 2,386 lb (with dual hydraulics) |
| Standard fuel tank capacity | 937 lb |
| Engine type | Safran Helicopter Engines Arriel 2D |
| Takeoff power | 710 kW / 952 shp |
Configurations
Four passengers
The one pilot and four passenger configuration is ideal for VIP or private and business aviation. With forward-facing seats and a spacious cabin, passengers can make the most of their time in the air.
Five passengers
The H125’s standard seating configuration of one pilot and five passengers complements commercial transport operations. Passengers benefit from ample legroom and a comfortable ride.
Six passengers
The six-passenger configuration is often used by tourism and sightseeing operators. The H125’s compact cabin means every passenger has the opportunity for breath-taking views.
Documents
Civil Range Brochure
Pdf5.45 MB
Civil Range Brochure
Brochure H125
Pdf8.49 MB
Brochure H125
Mission-Powerline Brochure
Pdf8.35 MB
Brochure Mission Powerline
Mission-HEMS Brochure
Pdf8.34 MB
LIFE SAVING
Mission Firefighting Brochure
Pdf8.47 MB
Firefighting
Mission Search and Rescue Brochure
Pdf11.15 MB
Brochure Mission Search and Rescue
Brochure Mission Police
Pdf8.39 MB
Brochure LAW ENFORCEMENT
Did you know?
| Total accumulated flight hours for single-engine AS350s and AS550s | 31.9+ million |
| Fleet leader: | 39,000 flight hours on an in-service AS350 B2 (fleet leader of the in-service Airbus Helicopters fleet) |
| Longest H125 in service: | 46 years (an AS350B1) |
